PostSwap™ Adjustable Bolt-Down Post Support | 75–200mm Galvanised Steel Timber Post Base
The PostSwap™ Adjustable Bolt-Down Post Support provides one heavy-duty fixing solution for multiple timber post sizes. Its adjustable internal plates move inward to grip and centre the post securely, making it ideal where timber dimensions vary or where you want greater flexibility from a single post support.
Made from 3mm galvanised steel, the four-piece WrapLock construction fits around the post and bolts together without welding. The post can also be removed and replaced later without having to replace the complete base.
Ideal for pergolas, gazebos, fencing, decking, patios, carports, canopies, privacy screens and other timber structures.
Key Features
- Adjustable 75–100mm post fit
- Built-in adjustment plates grip and centre the timber
- Heavy-duty 3mm galvanised steel
- Four-piece WrapLock construction
- No welding required
- Overlapping corners for additional strength
- Three side bolts per side
- 5mm thick bolt-down base plates
- Slotted mounting holes for easier alignment
- Bolt-down installation on concrete and suitable solid surfaces
- Replaceable-post design
- Corrosion-resistant galvanised finish
- Suitable for outdoor applications
75–100mm Model Specifications
- Post range: 75–100mm
- Overall height: 160mm
- Approx. base footprint: 120 × 120mm
- Main steel thickness: 3mm
- Base plate thickness: 5mm
- Mounting slot: approx. 13 × 30mm
